Question Oh no!! Oil and water don't mix right?

Okay all you smart turbo guys, I need your help!! I have a problem, no a major problem. A little back ground first. Months ago when a buddy of mine and I tore the 5.0 down I knew the Edelbrock heads were "O" ringed, and I swear the gasket that was on there was Fel-pro 1011. I even went on-line and asked around about what gaskets were recommended.

So when the block returned from the machine shop we slapped the 1011's on and I installed the 5.0, turbo, and everything else that needed to be installed so I could fire it up this Sunday. When I poured in the Antifreeze I noticed nice green liquid seeping out from between the heads and the block.

Yes the ARP heads studs, bolts and every other stupid bolt and nut are torqued down to required specs. The only thing I can think of right now is it looks like the "O" rings are hitting the block and not letting the gasket get sandwitched between the heads and block. In other words the "O" rings in the heads are resting on the block.

We all know what is going to happen if I start this baby up. Nice white foamy oil/water mixture in my new bearings, turbo, and every other nook and cranny. It looks like I have no choice but to tear it down once again.

So if the 1011 are not working with my "O" ringed heads, what gaskets do you all recommend that I use? Are there other threads on this topic? Or could you give me some engine building shop names that you trust so I could talk to them about my little problem?

I did do a little research just now and it looks like I should have used Fel-pro Loc-Wire O-ring head gasket Fel 1006. Any thoughts?

Thanks,
Ben Semper Fi






88 Notch. QT PT 6776 turbo kit, Edelbrock RPM, Cometic, Crane 1.6, f303, LW bell, 6 pt., 3.73, strange adj. 6AL, MB Jr. upper/lower control arms, T5-Z, SRP pistons, main support, windage tray, FAST XFI, Strange spool & 33 spline axles, c-clip, Spec III, Flaming River man. rack, Team-Z anti-roll

Last edited by D O A; 03-17-2009 at 10:10 PM.
D O A is offline
Sponsored Links
Advertisement

post #2 of 16 Old 03-17-2009, 09:46 PM
Registered User

WHITEMACH's Avatar

Trader Feedback: (23)
Join Date: Feb 2008
Location: jensen beach FL
Posts: 1,235
i would say fel pro 1006!


2012 GT AUTO
bbr tune ,bbr x-pipe,jlt cold air
[email protected]
WHITEMACH is offline
post #3 of 16 Old 03-17-2009, 09:49 PM
Registered User

Trader Feedback: (250)
Join Date: Aug 2004
Location: Ephrata,pa
Posts: 10,180
yup use the felpro 1006 gaskets.


1989- gt full drag build in progress..
1991- emerald coupe- stroked, caged & sprayed
1999 cobra- 5.0 stroker and single turbo coming soon
eighty8gtfiveo is offline
Sponsored Links
Advertisement

post #4 of 16 Old 03-18-2009, 09:06 AM
Registered User

cobras281's Avatar

Trader Feedback: (5)
Join Date: Aug 2004
Location: Howell, NJ
Posts: 1,511
is the block machined to accept orings?
cobras281 is offline
post #5 of 16 Old 03-18-2009, 11:45 AM

Trader Feedback: (0)
Join Date: Mar 2009
Posts: 146
Anti-freeze seepage

Did you coat your head bolts or stud threads with teflon sealant.That would be the lower bolts that thread into the water jacket where you seem to be leaking.

Last edited by Alan VanBuren; 03-18-2009 at 11:50 AM.
Alan VanBuren is offline
post #6 of 16 Old 03-18-2009, 03:23 PM
Registered User

fred50stang's Avatar

Trader Feedback: (0)
Join Date: Apr 2000
Location: Newnan GA
Posts: 407
That sucks. Ya, you def. need some o-ring gaskets on your set-up if the heads are cut for it.

One thing I have done in a pinch was, disconnect the oil line and primed the oil pump and let the old oil run that into a bucket and refilled with fresh oil into the lifter valley. It took about a case or two of oil but it worked and had no issues after that.
fred50stang is offline
post #7 of 16 Old 03-18-2009, 05:35 PM
Registered User

jturmanator's Avatar

Trader Feedback: (7)
Join Date: Jul 2007
Location: MS
Posts: 2,069
Quote:
Originally Posted by Alan VanBuren View Post
Did you coat your head bolts or stud threads with teflon sealant.That would be the lower bolts that thread into the water jacket where you seem to be leaking.
x2

Stock block, GT40 heads, Explorer intake, 67mm, 10lbs, 431HP 497TQ on 110 octane. 12.01 @ 123
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
jturmanator is offline
post #8 of 16 Old 03-18-2009, 07:01 PM Thread Starter
Registered User

D O A's Avatar

Trader Feedback: (0)
Join Date: Jul 2007
Location: SCAPPOOSE OREGON
Posts: 192
The block is not machine to accept but the heads are.

When we tore the 306 down every single ring was still in the groove that was machined into the heads. I wish I could have read what head gasket was used but they were toast.

I talked to a engine shop today that even had an article in MM&FF and they said I need to use 1011-2 which is a pre-flattened copper wire with a 0.39 thickness. I think I installed 1011-1 steal wire with a 0.41 thickness. So I will try those and see what happens. What I don't understand is why can't I remove the rings that are in the head now and use the 1006's? Maybe the new gasket rings won't fit with what is already machined into my heads? I'm just glad I did not crank the thing over.

I am 99% sure we used sealant on the ARP head studs that went through the water jacket. I will have to double check that too.

Good tip, I will do that if nec.

Thanks!

88 Notch. QT PT 6776 turbo kit, Edelbrock RPM, Cometic, Crane 1.6, f303, LW bell, 6 pt., 3.73, strange adj. 6AL, MB Jr. upper/lower control arms, T5-Z, SRP pistons, main support, windage tray, FAST XFI, Strange spool & 33 spline axles, c-clip, Spec III, Flaming River man. rack, Team-Z anti-roll
D O A is offline
post #9 of 16 Old 03-18-2009, 07:37 PM
Registered User

danny carvalho's Avatar

Trader Feedback: (19)
Join Date: Aug 2003
Location: massachusetts
Posts: 685
When your heads are machined for receiver grooves (loc wires), the head gasket itself will have the wires built in. You don't use seperate o rings that squish into the gasket, those o-rings are way taller than the receiver grooves cut into your heads (.010) hope this helps.

One owner 50,000 miles Dart 363, oliver rods, Karl's East Coast custom Y2k 82mm turbonetics, TW stage 2 Fox Lake, PMS, Victor intake, PMAS custom pipe for 85 lb/hr inj. T56 Magnum 6 speed w/Spec3+,756 rwhp 746 tq (pump gas, 14psi, 20*) 840 rwhp 848 tq (race gas, 16.5psi, 20*) SOLD
-2014GT/CS

Last edited by danny carvalho; 03-18-2009 at 07:41 PM.
danny carvalho is offline
post #10 of 16 Old 03-18-2009, 07:57 PM
Registered User

WHITEMACH's Avatar

Trader Feedback: (23)
Join Date: Feb 2008
Location: jensen beach FL
Posts: 1,235
if the heads are o ringed 1006 if you had wire put in the head thats another story ???so witch is it???


2012 GT AUTO
bbr tune ,bbr x-pipe,jlt cold air
[email protected]
WHITEMACH is offline
post #11 of 16 Old 03-19-2009, 12:03 AM
Registered User

jturmanator's Avatar

Trader Feedback: (7)
Join Date: Jul 2007
Location: MS
Posts: 2,069
I used the Fel pro 9333's ??? cheap but had no problems yet.

Stock block, GT40 heads, Explorer intake, 67mm, 10lbs, 431HP 497TQ on 110 octane. 12.01 @ 123
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
jturmanator is offline
post #12 of 16 Old 03-19-2009, 09:46 AM
Registered User

strokercharged95GT's Avatar

Trader Feedback: (2)
Join Date: Jul 2003
Location: Tampa
Posts: 1,196
best thing i ever did was deck my o-ringed heads and ran regular gaskets.

1995 Mustang GT - 347 - PT7576
2004 Mazda RX8 - 13B-REW BWS362
2013 Mercedes GLK-350
strokercharged95GT is offline
post #13 of 16 Old 03-19-2009, 11:26 AM
Registered User

1995gtCPE's Avatar

Trader Feedback: (34)
Join Date: Nov 2002
Location: Ohio
Posts: 1,921
Quote:
Originally Posted by jturmanator View Post
I used the Fel pro 9333's ??? cheap but had no problems yet.
9333-pt1 FTW. 1011's are not recommended for boost.

OP, the seepage is most likey from the lower studs. Did use teflon sealer on them?

80 coupe, N/A 347, tko500 1.34, 6.30 @ 109.01, 9.87 @ 137.06

16 GT, daily driver on pump 93, Procharger 1.42, 6.31 @ 109.59, 9.80 @ 141.57
1995gtCPE is offline
post #14 of 16 Old 03-19-2009, 08:29 PM Thread Starter
Registered User

D O A's Avatar

Trader Feedback: (0)
Join Date: Jul 2007
Location: SCAPPOOSE OREGON
Posts: 192
Pulled the driver's side head off and we did use sealant on the studs that are in the water jackets, gasket was installed correctly and it is a 1011-2 which is the gasket I was told would fix my problem. Well it didn't. It looks like to me these are "O"-rings, not sure what a loc-wire looks like and if they are built into the gasket like the 1006's than I have something different. Does anyone know the Fel-Pro tech line? Tired of spinning my wheels. I may just take it to my local machine shop, have them remove the rings and deck the heads and move on.









88 Notch. QT PT 6776 turbo kit, Edelbrock RPM, Cometic, Crane 1.6, f303, LW bell, 6 pt., 3.73, strange adj. 6AL, MB Jr. upper/lower control arms, T5-Z, SRP pistons, main support, windage tray, FAST XFI, Strange spool & 33 spline axles, c-clip, Spec III, Flaming River man. rack, Team-Z anti-roll
D O A is offline
post #15 of 16 Old 03-19-2009, 09:48 PM
Registered User

danny carvalho's Avatar

Trader Feedback: (19)
Join Date: Aug 2003
Location: massachusetts
Posts: 685
Those heads have definitely been cut for LOC WIRE head gaskets NO DOUBT!!

One owner 50,000 miles Dart 363, oliver rods, Karl's East Coast custom Y2k 82mm turbonetics, TW stage 2 Fox Lake, PMS, Victor intake, PMAS custom pipe for 85 lb/hr inj. T56 Magnum 6 speed w/Spec3+,756 rwhp 746 tq (pump gas, 14psi, 20*) 840 rwhp 848 tq (race gas, 16.5psi, 20*) SOLD
-2014GT/CS
danny carvalho is offline
post #16 of 16 Old 03-19-2009, 10:39 PM
Registered User

Blackfive0's Avatar

Trader Feedback: (62)
Join Date: Oct 2004
Location: Midlothian,VA
Posts: 2,109
Quote:
Originally Posted by jturmanator View Post
I used the Fel pro 9333's ??? cheap but had no problems yet.
x2
love those gaskets. I know of a couple cars making 18psi with those and zero problems. just a good tune.

Big Bore Boss 347 FTI 225cc High Port, FTI Cam, Box R Intake under stock hood, T-56 Magnum, 4.30 gears.
